As silver prices continue to fluctuate and trend upward, mirror manufacturers are increasingly reassessing mirror production.
Aluminum mirror coating offers a more cost-stable and scalable alternative, while maintaining excellent optical performance and surface quality. This shift is driven not by short-term pricing, but by long-term cost predictability, supply stability, and production efficiency.
Our aluminum mirror vacuum coating machines are purpose-built for this transition, enabling manufacturers to reduce material cost uncertainty, simplify production planning, and maintain consistent output quality over long-term operationc
This machine is a high-performance vacuum sputtering system designed for industrial-scale mirror manufacturing. The system delivers uniform aluminum film deposition with high reflectivity, strong adhesion, and consistent quality across large glass.
Designed for continuous production environments, the machine integrates advanced magnetron sputtering technology, automated control systems, and modular configurations to meet the requirements of modern mirror manufacturers.
Substrate Size: Max. 2440×3600mm (customizable)
Cycle time: 45-180s
Key Features of Magnetron Sputtering Aluminum Mirror Coating Machine
* Magnetron sputtering technology optimized for aluminum deposition
* Stable plasma generation and precise film thickness control
* Excellent coating adhesion and surface smoothness
* Designed for large glass used in architectural and decorative aluminum mirrors* Uniform coating performance across the entire surface area
* PLC-based control system with HMI interface * Automated process recipes for repeatable results * Reduced operator dependency and high production uptime
* Eliminates direct dependence on silver raw material pricing * Predictable coating cost structure for long-term planning * Suitable for high-volume mirror production
* Global installation and commissioning support * Operator training and process guidance included * Long-term technical support and spare parts availability
| Glass Size | 2440x1830mm | 3600x2440mm |
| Sputter cathodes | 12 pairs | 16 pairs |
| Sputtering power | 100x12 KW | 100x16 KW |
| Cycle time | 45~180s | |
| Ultimate pressure | 8x10-4Pa | |
| Uniformity | 士2.0% | |
| Heating system | Max 350°C | |
| Coating | Al films | |
| Application | Aluminum mirror | |
